Accepting payments

This is the core merchant flow: generate a payment code, show it, check it until it is paid or expires.

5.1 Generate a payment code

POST {baseUrl}/api/code/generate

{
  "reference": "ORD-10045",
  "narration": "Order ORD-10045",
  "currency": "USD",
  "amount": 450,
  "type": "PAYMENT"
}

• amount is integer cents: 450 is US$4.50.
• reference is your order or payment reference. Make it unique per code.
• narration appears on your InnBucks merchant statement. Put your own unique reference in it so you can reconcile each payment (12.6).

Response (abridged):

{
  "stan": "ORD-10045",
  "authNumber": "9006055639",
  "processedDateTime": "2026-02-25 15:48:42.208",
  "responseCode": "00",
  "responseMsg": "Approved or completed successfully",
  "code": "535403380",
  "currency": "USD",
  "amount": 450,
  "qrCode": "<base64 image>",
  "description": "Order ORD-10045"
}

Save code, authNumber, stan and the time you generated it against the order before showing anything to the customer.

5.2 Show the code to the customer

Show all of these together:

1. The InnBucks logo (use the official artwork, see 5.6).
2. The amount and currency the customer will pay.
3. The code in large, copyable digits.
4. The QR code, decoded from qrCode.
5. The instruction: pay in the InnBucks app or dial *569#.
6. A countdown from 10:00, because the code expires after 10 minutes.
7. On mobile, a Pay using InnBucks App button (5.3).

InnBucks’ own example of the web version:

A web checkout page showing the payment code, the QR code and the remaining time.


<!-- the qrCode value from the generate response goes after "base64," -->
     width="220" height="220">

5.3 Add the deep link on mobile

If your checkout runs on a phone, add a Pay using InnBucks App button. It opens the customer’s InnBucks app on the payment screen, so they only enter their PIN and confirm. It is the lowest-friction way to pay, and InnBucks strongly recommends it for mobile solutions.

Environment	Deep link
Test	zw.co.innbucksnova.test://purchase?paymentToken={code}
Production	com.innbucks.customer://purchase?paymentToken={code}

{code} is the code from the generate response. For example, for code 701564 in production: com.innbucks.customer://purchase?paymentToken=701564.

The deep-link journey: checkout → InnBucks app PIN entry → pre-filled payment confirmation.

• Choose the scheme from configuration (INNBUCKS_ENV), never by hard-coding it: the test scheme opens only the test app, and the production scheme only the live app.
• Keep showing the code and QR code next to the button. The deep link does nothing if the app isn’t installed, and a customer can always pay by USSD instead.
• Don’t show the button on desktop: there is no app to open.

5.4 Check the status

POST {baseUrl}/api/code/inquiry

{
  "code": "535403380"
}

Response:

{
  "stan": "1655116056",
  "authNumber": "7875",
  "processedDateTime": "2022-07-05 12:11:47.067",
  "responseCode": "00",
  "responseMsg": "Approved or completed successfully",
  "code": "535403380",
  "amount": "450",
  "status": "New",
  "timeToLive": "576sec",
  "description": "Order ORD-10045"
}

Read status only when responseCode is "00":

status	Meaning	What to do
New	Generated, not yet paid	Keep checking
Claimed	The customer completed payment against the code	Paid. Fulfil the order
Paid	The customer completed payment against the code	Paid. Fulfil the order
Expired	The 10-minute validity passed without payment	Final. Offer a new code
Timed Out	The transaction window passed without payment	Final. Offer a new code

InnBucks’ guidelines describe a paid code as Claimed; the API document lists both Claimed and Paid as “finalised by the customer”. Treat both as paid. Compare status values ignoring case and spaces (Timed Out, TIMED_OUT and TimedOut are the same).

Check at most once every 30 seconds per code, from 30 seconds after you generate it, until the status is final. InnBucks asks for this explicitly: faster checking loads their servers and does not make payments faster. timeToLive (for example "576sec") tells you how long the code has left.

5.5 Put it together

customer clicks "Pay with InnBucks"
  └─▶ your server: create order (status: awaiting_payment)
        └─▶ generate code (amount in cents, reference + narration = order ref)
              └─▶ save code, authNumber, generated_at on the order
                    └─▶ show logo, amount, code, QR, *569#, countdown (+ deep link on mobile)
background job, every 30 s:
  inquiry(code) ─▶ Claimed / Paid ──▶ mark order paid, fulfil, show success
                ─▶ Expired / Timed Out ──▶ mark code expired, offer "generate a new code"
                ─▶ New ──▶ check again in 30 s (stop after ~11 minutes: mark "unknown", review)

• Run the status checks in a background job or queue, not inside the customer’s web request. The browser can poll your server for the order status.
• Fulfil only after an inquiry says Claimed or Paid. Never trust a customer’s “I’ve paid” button or a screenshot.
• If the customer asks for a new code, keep checking the old code until it is final too. A customer may still pay it.

5.6 Brand and display guidelines

InnBucks reviews your customer journey during UAT for branding consistency (10.3). Use InnBucks’ own logo artwork and colours.

Approved InnBucks logo variants: use the white version on dark backgrounds and the navy version on light ones.

InnBucks brand colours: Pantone and CMYK values from InnBucks’ colour guide; HEX values sampled from InnBucks’ vector logo artwork.

Colour	Pantone	CMYK	HEX (from the logo artwork)
Navy	2767 C	C100 M88 Y40 K45	#0E2240
Yellow	7409 C	C6 M30 Y97 K0	#EDB017
Purple	258 C	C55 M80 Y0 K0	#803FA4
Green	346 C	C72 M0 Y56 K0	#4CC18C
Red	485 C	C5 M100 Y99 K0	#E31D25
White	White	C0 M0 Y0 K0	#FFFFFF

• Don’t redraw, recolour, stretch or crop the logo. Use the navy wordmark on light backgrounds and the white one on dark backgrounds.
• A navy (#0E2240) Pay using InnBucks App button with white text matches InnBucks’ example checkout (5.3).
• The HEX values are for screens and come from InnBucks’ own logo file; the colour guide itself gives only Pantone and CMYK. For print, use the Pantone or CMYK values.
• Use the name InnBucks (capital I, capital B, one word).

---
